EMCORE™ 20 MIL VINYL PLANK
LUXURY VINYL TILE
Description
Emcore by Emser Tile™ is a 5MM SPC product with a 20 mil wear layer. This collection of vinyl plank products is appropriate for any interior flooring application. Emcore by Emser Tile™ is a solid-core construction, waterproof material that is stain-, scratch- and dent-resistant. It is offered with 15 different graphic faces and a Uniclic® Locking System that provides the realistic look of wood with easier installation and maintenance.
View UNICLIC Locking System Installation and Maintenance Instructions
Technical Specifications
6 Colors | 1 Size
Technical Specifications
| Nominal Size (in.) | 7" x 48" |
| Edge Detail | Interlock |
| Faces | 15 |
| Thickness (mm)* | 5mm |
| Wear Layer |
20mil |
| Solid Core |
3.0mm |
| Underlayment | 1.5mm IXPE Pad |
| Click System | Uniclic® (Short & Long) |
| UV Coating | Yes |
| Water Resistant | Yes |
| Warranty | 35 Year Limited Residential Wear Warranty 5 Year Limited Commercial Wear Warranty |
The Emcore™ collection by Emser Tile™ contains no phthalates or heavy metal and is 100% virgin vinyl.
Testing
| Method | Results |
| Squareness ASTM F2421 | PASS |
| Dimensional Tolerances ISO 24337 | PASS |
| Dimensional Stability ASTM F2199 | PASS |
| Slip Resistance DIN 51130 | R 10 |
| Residual Indentation ASTM F1914 | PASS (0.001”) |
| Deep Abrasion ASTM D4060 | 25,000 CYCLES |
| Resistance to Bacteria ASTM G21 | 0 - PASS |
| Castor Chair Resistance ANSI LF-01 | PASS (25,000 CYCLES) |
| Heat Stability ASTM F1514 | PASS (<2MM) |
| Resistance to Chemicals ASTM F925 | PASS |
| Smoke Density ASTM E662 | <450 |
| Impact Sound Reductions ASTM E2179 | Δ IIC 55 dB |
| Stain Resistance ASTM E423 | NOT AFFECTED |
| Heavy Metals ASTM F963-16 | FREE - PASS |
| Emissions Testing CDHP/CAL 1350 | PASS (0g/L) |
| VOC Requirements ASTM D5116 | PASS (0g/L) |
Sizes and Trim
7" x 48"
TRIM
Usage
| USAGE TYPES: | YES/NO |
| COMMERCIAL FLOOR | YES |
| RESIDENTIAL FLOOR | YES |
The usage chart is provided as a general guide only. Actual job site conditions may change a product’s suitability for a specific application. If special conditions apply, please contact an Emser representative for clarification of use prior to purchasing.
